Brinkmann
Brinkmann Audio Edison Mk II - MM/MC Phono Stage
Quantity:
Edison Mk II
MM/MC Phono Stage. Variable gain on 16 positions. Variable impedance on 12 positions. Inputs: 1 RCA, 2 XLR/RCA. XLR output. Tube output stage. Granite base included. Separate power supply stage.
Dimensions with base (LxWxH): 420x95x310mm.
Weight: 24Kg with granite base.
MM/MC Phono Stage. Variable gain on 16 positions. Variable impedance on 12 positions. Inputs: 1 RCA, 2 XLR/RCA. XLR output. Tube output stage. Granite base included. Separate power supply stage.
Dimensions with base (LxWxH): 420x95x310mm.
Weight: 24Kg with granite base.
Other features
- Inputs: 2RCA/XLR, 1 RCA
- Gain: adjustable from 49 to 73 dB
- Input impedance: 50 ohms to 47 kohms
- Output level: maximum +/- 8V balanced
- Output impedance: 1k ohm balanced
- Dimensions: 420x95x310mm
- Weight: Edison Mk II 12kg, granite base 12kg, power supply 3.2kg
