Hi-End stereo preamplifier equipped with Slovakia JJ Electronics ECC803 and ECC802 valves, 4 line inputs, 1 Phono MM/MC input, 2 pre out outputs, 1 Tape output, tone control, remote control, dimensions (WxHxD) 440x169x307mm, weight 13, 3 kg. Silver/Wood finish.
CL-38u An attractive custom control amplifier for vacuum tubes
The CL-38uC uses SRPP (Shunt Regulated Push Pull) circuitry for all stages to achieve the highest possible sound quality. A true phono equalizer is included, the MC-low and MC-high impedance (gain) inputs each have independent MC transformers and are selectable using the MC impedance toggle switch. Tone controls allow the listener to fine-tune the sound quality. The refined exterior design and newly added balanced inputs make this tube control amplifier a new standard for its generation.
The CL-38uC uses SRPP (Shunt Regulated Push Pull) circuitry for all stages to achieve the highest possible sound quality. A true phono equalizer is included, the MC-low and MC-high impedance (gain) inputs each have independent MC transformers and are selectable using the MC impedance toggle switch. Tone controls allow the listener to fine-tune the sound quality. The refined exterior design and newly added balanced inputs make this tube control amplifier a new standard for its generation.
| Input sensitivity/ input impedance |
PHONO (MM): 2.0mV/47kΩ PHONO (MC high): 0.3mV/100Ω PHONO (MC low): 0.08mV/30Ω LINE: 190mV/50kΩ BAL.LINE: 190mV/20kΩ *2 |
|---|---|
| Output/output impedance | Rated 1V/300Ω |
| Frequency response | PHONO: 20Hz to 20kHz (±0.5dB) LINE/BAL.LINE: 10Hz to 70kHz (within -3.0dB) |
| Total harmonic distortion | 0.006% or less (1kHz) 0.06% or less (20Hz to 20kHz) |
| S/N ratio (IHF-A) | PHONO (MM): 68dB or more PHONO (MC high): 63dB or more PHONO (MC low): 60dB or more LINE/BAL.LINE: 100dB or more |
| Tone control | ±8dB, selectable frequency range BASS: 150/300/600Hz, TREBLE: 1.5k/3k/6kHz |
|---|---|
| Low cut | 30Hz(-6dB/oct.) |
| Circuit | SRPP |
| Vacuum tubes | ECC83S×3, ECC82×5 |
| Power supply | 230V~(50Hz)/115V~(60Hz) |
| Power consumption | 35W |
| External dimensions | 440(W) x 169(H) x 307(D) mm 19mm front panel knob and 12mm rear panel terminals are included in the depth measurement |
| Net weight | 13.3kg (main unit) |
| Accessories | Remote control (RA-19), Power cable |
| *2 This unit uses transformer equipped balanced inputs. Since the maximum input level at the balanced inputs is equivalent to 2.5 Volts, please be aware that the audio signal may be distorted if you connect a device with a higher output level (higher output voltage). There is no problem when using Luxman products (CD players etc.). For details, please refer to the instruction manual for the equipment to be used. |
